(EN / TH)

GA9061
Angle Grinder

GA9061
Angle Grinder

Angle Grinder 9" 2,200 W Large Trigger Switch

  

๐ Developed for heavy duty applications such as foundry grinding ๐ SJS 2 (Super Joint System 2) provides increased machine durability by absorbing vibration ๐ Motor more durable for heavy duty applications ๐ Design of anti layer short of armature ๐ Rigid, low-absorbent motor housing to reduce water absorption ๐ Adoption of spiral spring type brush holders yet with a compact body ๐ Compact design at only 450 mm (17-3/4") long ๐ Lightweight for high production work with less fatigue ๐ Switch cover and sponge minimize entering of metal particles to switch terminals to improve the protection against electric leakage ๐ Newly designed side handle provides more comfort and control ๐ Newly designed shaft lock enables to press the button from a slant angle ๐ Protection of serial No. label with a transparent portion of brush holder cover ๐ Powerful 2,200 W motor delivers 6,600 RPM for the most demanding applications ๐ Spiral bevel gears for smoother rotations, quieter gear noise and a more efficient transfer of energy ๐ Three position adjustable side handle for operator covenience ๐ Soft grip provides increased comfort on the job ๐ Large trigger switch for easy operation ๐ Lock lever for continuous use operation (For tool with Lock-on switch)

Standard Equipments : Side grip, Wheel cover, Lock nut wrench


Technical specifications

Continuous Rating Input 2,200 W
Wheel Diameter 230 mm
No Load Speed 6,600 minˉ¹
Switch Type Large Trigger Switch
Dimensions (L x W x H) 450 x 250 x 145 mm
Net weight 5.63 - 7.99 kg
Power Supple Cord 2.5 m
Carbon Brush 218
Double Insulation
Dust Collection
