GA9020
Angle Grinder

Angle Grinder 9" 2,200 W Large Trigger Switch

๐ Powerful 2,200W Motor Delivers 6,600 RPM for Faster Material Removal ๐ Spiral bevel gears for smoother rotations and a more efficient transfer of energy ๐ Labyrinth construction minimizes debris from penetrating the motor, bearings and gears for longer tool life ๐ Zig-zag varnish protects the armature coil from dust and debris for longer motor life ๐ Large rubber tool rest protects work piece from damage ๐ AC/DC switch for use with alternative power source ๐ Rubberized back handle for increased operator comfort ๐ Externally accessible brushes for easy serviceability ๐ Three position adjustable side handle for operator covenience ๐ "Tool-less" wheel guard for more convenient adjustments ๐ Push button spindle lock for operator convenience ๐ Wheel cover protects operator from accidental scattering of broken wheel or workpiece with minimal wheel cover movement ๐ Can be connected to dust extraction system with optional dust collecting wheel guard ๐ Double insulated

Standard Equipments : Side grip, Wheel cover, Lock nut wrench

Technical specifications

Continuous Rating Input	2,200 W
Wheel Diameter	230 mm
No Load Speed	6,600 minˉ¹
Switch Type	Large Trigger Switch
Dimensions (L x W x H)	473 x 249 x 140 mm
Net weight	5.76 - 8.05 kg
Power Supple Cord	2.5 m
Carbon Brush	204

GA9020 Angle Grinder

GA9020 Angle Grinder

Angle Grinder 9" 2,200 W Large Trigger Switch

Technical specifications
