GA6020
Angle Grinder

Angle Grinder 6" 1,050 W Finger Trigger Switch

๐ SJS Mechanical Clutch System Helps Minimize Motor and Gear Damage ๐ Powerful 1,050W motor delivers 10,000 RPM to handle the most demanding applications ๐ SJS technology is a mechanical clutch system that helps minimize motor and gear damage by allowing the drive shaft to slip if the wheel is forced to stop ๐ Electric brake for maximum productivity ๐ "Tool-less" wheel guard for more convenient adjustments ๐ Spiral bevel gears for smoother rotations and a more efficient transfer of energy ๐ Zig-zag varnish protects the armature coil from dust and debris for longer motor life ๐ Labyrinth construction minimizes debris from penetrating the motor, bearings and gears for longer tool life ๐ No lock-on feature for more convenience ๐ Side handle can be installed on either side of the tool ๐ Push button spindle lock for operator convenience ๐ Connectable to Makita vacuum cleaner with optional dust collecting wheel guard ๐ Wheel cover protects operator from accidental scattering of broken wheel or workpiece with minimal wheel cover movement ๐ Double insulated

Standard Equipments : Depressed center wheel, Side grip, Wheel cover, Lock nut wrench

Technical specifications

Continuous Rating Input	10,50 W
Wheel Diameter	150 mm
No Load Speed	10,000 minˉ¹
Switch Type	Finger Trigger Switch
Dimensions (L x W x H)	356 x 169 x 120 mm
Net weight	✓
Power Supple Cord	2.5 m
Carbon Brush	303

GA6020 Angle Grinder

GA6020 Angle Grinder

Angle Grinder 6" 1,050 W Finger Trigger Switch

Technical specifications
