9556HB
Angle Grinder

Angle Grinder 4" 840W Toggle Switch

๐ Reliable machined gears provide twice or more longer service life ๐ Powerful 840 W motor delivers 11,000 RPM for high output power ๐ Compact design with small diameter barrel and lightweight for added comfort ๐ Protective zig-zag varnish seals the armature from dust and debris for longer tool life ๐ Thicker coil wires are wound more closely to reduce heat and energy loss ๐ Labyrinth construction seals and protects the drive gear and bearings from contamination for longer tool life ๐ Dust-proof ball bearing on spindle for durability ๐ O rings for protection from grease-leakage ๐ Spiral bevel gears for smoother rotations and a more efficient transfer of energy ๐ Toggle switch for easy operation ๐ Side grip can be positioned on both sides for operator convenience ๐ Wheel cover protects operator from accidental scattering of broken wheel or workpiece with minimal wheel cover movement ๐ Push button spindle lock for operator convenience ๐ Gear housing can be rotated to suit most cutting and grinding applications ๐ Double insulated

Standard Equipments: Grip complete, Lock nut wrench, GRINDING WHEEL

Technical specifications

Continuous Rating Input	840 W
Wheel Diameter	100 mm
No Load Speed	11,000 minˉ¹
Switch Type	Toggle Switch
Dimensions (L x W x H)	271 x 118 x 97 mm
Net weight	1.6 - 2 kg
Power Supple Cord	2.5 m
Carbon Brush	325

9556HB Angle Grinder

9556HB Angle Grinder

Angle Grinder 4" 840W Toggle Switch

Technical specifications
