SK700GD
Rechargeable Green Multi Line Laser

12V Max Rechargeable Green Multi Line Laser

  

Compare

๐ Rotary base with eccentric rotation mechanism reduces setup time; Vertical laser lines can rotate around the defined plumb point up to 10° left and right (with a dial for fine adjustment); Eccentric rotation mechanism enables the laser body to rotate without changing the position of the defined plumb point, enabling easy line positioning ๐ Three full 360-degree lines can be projected ๐ Full 360-degree line is created by letting the laser from a light source reflect on a cone mirror ๐ High brightness green laser for increased visibility in outdoor or bright job sites ๐ 4 Horizontal lines & 4 Vertical lines ๐ High accuracy +/-2 mm @ 10 m ๐ Indication method: Automatic vertical line indication by gimbal mechanism*¹ ๐ Control method: Magnet damper method control

Standard Equipments: Target Plate, Adapter, Soft Bag Any accessories shown are not necessarily supplied as standard equipment.


Information & Technologies

Technical specifications

Leveling accuracy 2 mm / 10 m
Self-leveling range 4 °
Laser fan angle horizontal : 360°
Vertical : 360°
Number of laser lines 8
Laser type: Laser class 2 515 nm
Operating temperature -10 - 50°C °C
Protection class IP54
Operating Time (Approx. Hours) 5
Dimensions (L x W x H) w/ BL1016/BL1021B : 149 x 104 x 153 mm
Net weight 0.99 - 1.2 kg (2.2 - 2.7 lbs.)
