DLS714
190 mm(7-1/2")Dual Slide Compound Miter Saw
18V X2 (36V) Slide Compound Miter Saw (7-1/2")
Other Products
๐ Two 18V LXT Li-Ion batteries deliver the power and performance for corded demands without leaving the 18V LXT platform ๐ High power delivered by 36V (18Vx2) DC Brushless motor enables to cut as fast as if you were using a corded slide compound miter saw ๐ Large cutting capacity; Crosscuts up to 52 x 300 mm (2-1/16" x 11-3/4") at 90° ๐ ADT (Automatic Torque Drive Technology) adjusts speed and torque during operation for optimum performance 4-Steel Rail Sliding System increaes rigidity to produce superior cuts
Any accessories shown are not necessarily supplied as standard equipment.
Material
Almi-num
Wood
MDF
Technical specifications
| Blade Diameter | 190 mm (7-1/2") |
|---|---|
| Miter Angle | 47°L / 57°R |
| Bevel Angle | 45°L / 5°R |
| Max cutting capacity | 90°: 52 x 300 mm (2-1/16 x 11-3/4") |
| at 45° left: 40 x 300 mm (2-1/16x11-3/4") | |
| at 5° right: 40 x 300 mm (1-9/16 x 11-3/4") | |
| No Load Speed (RPM) | 5,700 |
| Sound Pressure Level | 88 dB (A) |
| Sound Power Level | 97 dB (A) |
| Vibration Level (m/s²) | 2.5 m/s² |
| Dimensions (L x W x H) | 655 x 430 x 445 mm |
| Net weight | 12.6 kg(27.8lbs.) |
| LXT (Lithium-ion Xtreme Technology) | ✓ |
| BL Motor | ✓ |
| ADT | ✓ |
| Brake | ✓ |
| Soft Start | ✓ |
| Dust Collecting | ✓ |
| Bevel Cutting L45 R5 | ✓ |
