DLS212
350 mm(12")Slide Compound Miter Saw, Laser,
18V X2 (36V) Slide Compound Miter Saw (12")
Other Products
๐ Rail-forward design enables to be placed against a wall for maximizing work space ๐ High power delivered by 36V (18Vx2) DC Brushless motor enables to cut as fast as if you were using a corded slide compound miter saw ๐ Automatic torque Drive Technology (ADT) adjusts speed and torque during operation for optimum performance ๐ Large turn base supports workpiece securely for increased stability Integrated guide fences for increased rigidity and high cutting accuracy ๐ Single sliding system enables smooth operation to produce superior cuts ๐ Exclusive linear ball bearings engineered to deliver "dead-on" accurate cuts ๐ Electric brake for maximum productivity and increased operator safety. ๐ Incorporates Deep eXact cutting Technology (DXT) achieved by our consistent pursuit of cutting larger size workpiece but with higher accuracy.
Any accessories shown are not necessarily supplied as standard equipment.
Material
Almi-num
Wood
MDF
Technical specifications
| Blade diameter | 305(12) mm (") |
|---|---|
| Miter Angle | 60°L /60°R |
| Bevel Angle | 48°L /48°R |
| Max cutting capacity | 90° Miter : 107 x 363 (4-1/4 x 14-1/4) mm (") |
| 90° Miter : 92 x 382 mm(3-5/8 x 15") | |
| 45°Miter, L/R: 107 x 255 mm (4-1/4 x 10") | |
| 45°Miter, L/R: 92 x 268 mm (3-5/8 x 10-1/2) | |
| No Load Speed (RPM) | 4,400 |
| Sound Pressure Level | 95 dB (A) |
| Sound Power Level | 102 dB (A) |
| Vibration Level (m/s²) | 2.5 m/s² |
| Dimensions (L x W x H) | 898 x 690 x 725 mm |
| Net weight | 30.7-31.3(67.6-69.1) kg(lbs) |
| LXT (Lithium-ion Xtreme Technology) | ✓ |
| BL Motor | ✓ |
| ADT | ✓ |
| DXT - Deep and Exact Cutting Technology | ✓ |
| Brake | ✓ |
| Soft Start | ✓ |
| Bevel Cutting 45 LR | ✓ |
| Laser Marker | ✓ |
| Dust Collecting | ✓ |
