LS003G
Cordless Slide Compound Miter Saw
40V Max 305 mm (12") Slide Compound Miter Saw
Other Products
๐ High power delivered by 40Vmax BL motor enables to cut as fast as if you were using a corded slide compound miter saw ๐ Vacuum cleaner activation switch for increased comfort ๐ LED light with ink line aligning funciton ๐ Auto-start Wireless System (AWS) connects to compatible vacuum cleaners with Bluetooth ๐ Rail-forward design enables to be placed against a wall for maximizing work space ๐ Large turn base supports workpiece securely for increased stability
Standard Equipments: TCT Saw Blade, Dust Bag, Triangular Rule, Vertical Vise, Hex Wrench Any accessories shown are not necessarily supplied as standard equipment.
Material
Wood
MDF
Technical specifications
| Blade Diameter | 305 mm (12") |
|---|---|
| Miter Angle | 60° L 60° R |
| Bevel Angle | 48° L 48° R |
| Max cutting capacity | 0° Miter : 107 x 363 mm (4-1/4 x 14-1/4") |
| 45° Miter, L/R : 107 x 255 mm (4-1/4 x 10") | |
| No Load Speed (RPM) | 3,600 |
| Dimensions (L x W x H) | 898 x 690 x 725 mm |
| Net weight | 30.5 - 31.1 kg (67.2 - 68.6 lbs.) |
| XGT : Next Generation Technology | ✓ |
| BL Motor | ✓ |
| AWS (Auto-Start Wireless System) | ✓ |
| DXT - Deep and Exact Cutting Technology | ✓ |
| Brake | ✓ |
| Constant Speed | ✓ |
| Bevel Cutting 45 LR | ✓ |
| Dust Collecting | ✓ |
| Built-in Job Light | ✓ |
