TD111D
Cordless Impact Driver
12V Max (Assist Mode) 135 N·m Impact Driver
Other Products
๐ Ultra compact and slim design at only 135 mm (5-5/16") long ๐ Ultra lightweight for reduced operator fatigue ๐ Power-increased motor delivers 135 N·m (1,200 in.lbs.) of Max Torque in an ultra compact size ๐ 3-Mode operation: A-mode / Hard mode / Soft mode for multiple applications ๐ A-Mode feature helps eliminate "screw cam-out" and "cross threading" by driving at low speed until tightening begins ๐2-Speed power selection switch (0-3,000 / 1,300 RPM & 0-3,900 / 1,600 IPM) provides the user with precise fastening control for a wide range of applications
Standard Equipments: Phillips Bit, Belt Clip Any accessories shown are not necessarily supplied as standard equipment.
Information & Technologies
Technical specifications
| Capacity | Machine Screw : M4 - M8 mm (5/32 - 5/16") |
|---|---|
| Standard Bolt: M5 - M14 (3/16 - 9/16") | |
| High Strength Bolt : M5 - M12 (3/16 - 1/2") | |
| Coarse thread (in length) : 22 - 90 mm (7/8 - 3-1/2") | |
| Hex Shank | 6.35 mm (1/4") |
| No Load Speed (RPM) | Hard / Soft : 0 - 3,000 / 0 - 1,300 |
| Impacts per minute (IPM) | Hard / Soft : 0 - 3,900 / 0 - 1,600 |
| Max Fastening Torque | 135 N·m (1,200 in.lbs.) |
| Dimensions (L x W x H) | 135 x 66 x 210 mm |
| Net weight | 0.97 - 1.1 kg (2.1 - 2.5 lbs.) |
| CXT (Compact Extreme Technology) | ✓ |
| BL Motor | ✓ |
| XPT | ✓ |
| Variable Speed | ✓ |
| Brake | ✓ |
| Reversing | ✓ |
| Electronic 2-Speed | ✓ |
| Built-in Job Light | ✓ |
