M8701B
Combination Hammer
Combination Hammer 26 mm (1") Adapted for SDS-PLUS bits
๐ High performance and durability at less expense ๐ 3-Mode operation for "Rotation Only", "Hammering with Rotation" or "Hammering Only" for multiple applications ๐ Re-located operating mode lever for increased protection and durability ๐ Powerful 800 W motor delivers 2.3 J of impact energy to handle the most demanding applications ๐ One-touch sliding chuck for easy bit installation and removal ๐ Depth gauge for increased drilling consistency ๐ Recessed lock-on button for continuous use ๐ Double insulated
Any accessories shown are not necessarily supplied as standard equipment.
Material
Metal
Wood
Concrete
Technical specifications
| Continuous rating input | 710 W |
|---|---|
| Capacity | concrete: 22 mm (7/8") |
| Steel: 13 mm (1/2") | |
| Wood: 32 mm (1-1/4") | |
| Impact Energy | EPTA-Procedure 05/2009: 2.3 J |
| No Load Speed (RPM) | 0 - 1,200 |
| Dimensions (L x W x H) | 362 x 71 x 194 mm |
| Net weight | 2.7 - 3.1 kg (6 - 6.8 lbs.) |
| Power supply cord | 4.0 m (13.1 ft) |
| Double Insulation | ✓ |
| Variable Speed | ✓ |
| Reversing | ✓ |
| SDS-PLUS Shank | ✓ |
| Torque Limiter | ✓ |
| Carrying Case | ✓ |
| Carbon brush No. | 459 |
