235 mm (9-1/4")Magnesium Circular Saw

18V X2 (36V) Magnesium Circular Saw (9-1/4")



Other Products

๐ Cordless Mobility Allows for Smooth Operation without Worrying about Cord Handling even in Cutting Long Material ๐ 18V X2 LXT Li-Ion batteries, BL motor and TCT saw blade optimum for DC circular saw deliver powerful and smooth cutting similar to corded tool ๐ Lightweight by BL motor, magnesium diecast base ๐ Two 18V LXT Li-Ion batteries deliver the power and performance for corded demands without leaving the 18V LXT platform ๐ Auto-start Wireless System (AWS) connects to compatible vacuum cleaners with Bluetooth ๐ Automatic torque Drive Technology (ADT) adjusts cutting speed and torque during cut for optimum performance ๐ Overload alert using ADT indicator lamp ๐ Electric brake for maximum productivity and increased operator safety ๐ Magnesium components create lightweight saws that are well-balanced and jobsite tough

Any accessories shown are not necessarily supplied as standard equipment.

Information & Technologies




Technical specifications

Blade Diameter 235 mm (9-1/4")
Max cutting capacity 90° : 85 mm (3-3/8")
45° : 61 mm (2-3/8")
60° : 44mm (1-3/4")
No Load Speed (RPM) 4,500
Vibration Level Cutting Wood(m/s² or less) 2.5 m/s² or less
Sound Pressure Level 93 dB (A)
Sound Power Level 104 dB (A)
Dimensions (L x W x H) 413 x 196 x 316 mm
Net weight 5.3 - 6.0 kg (11.7 - 13.2 Its.)
LXT (Lithium-ion Xtreme Technology)
BL Motor
AWS (Auto-Start Wireless System)
Electric brake
Soft Start
Built-in Job Light
Carrying Case
