DWT310
804 N·m (593 ft.lbs.) Shear Wrench
18V X2 (36V) Shear Wrench
๐ Up to 14% Faster Fastening than Corded Model 6922NB Fastens 380 M22 (7/8") torque shear bolts with two 18V 6.0 Ah batteries ๐ Two 18V LXT Li-Ion batteries deliver the power and run time for corded demands without leaving the 18V LXT platform ๐ High power delivered by 36V (18Vx2) DC Brushless motor enables to fasten as fast as if you were using a corded shear wrench ๐ Delivers 804 N·m (593 ft.lbs.) of max torque for the most demanding applications ๐ Electric brake for maximum productivity and increased operator safety ๐ Extreme Protection Technology (XPT) engineered to provide increased dust and water resistance in harsh job site conditions ๐ Battery protection circuit protects against overloading, over-discharging and over-heating
Any accessories shown are not necessarily supplied as standard equipment.
Information & Technologies
Technical specifications
| Capacity High Strength Torque Shear Bolt(HTB) | M16, M20, M22 (5/8, 3/4, 7/8) (") |
|---|---|
| Capacity Super High Strength Torque Shear Bolt(SHTB) | M16, M20 (5/8, 3/4) (") |
| No Load Speed (RPM) | 14 |
| Max Fastening Torque | 804(593) N·m(in.lbs.) |
| Vibration Level (m/s²) | 2.5 m/s² |
| Sound Pressure Level | 83 dB (A) |
| Sound Power Level | 94 dB (A) |
| Dimensions (L x W x H) | 296 x 130 x 377 mm |
| Net weight | 6.5-7.1(14.3 - 15.7) kg(lbs) |
| LXT (Lithium-ion Xtreme Technology) | ✓ |
| BL Motor | ✓ |
| XPT | ✓ |
| Brake | ✓ |
| Carrying Case | ✓ |
