DTS141
Cordless Oil-Pulse Driver
Model DTS141 is a cordless oil-pulse driver powered by 18V Li-ion battery, featuring a compact and lightweight design thanks to the newly-developed oil unit and brushless motor. W/- Charger, Battery
Any accessories shown are not necessarily supplied as standard equipment.
Information & Technologies
Li-ion Ah
Material
Metal
Stainless
Almi-num
Wood
Stone
Concrete
Soft Tile
MDF
PVC
Plastics
Glass
Technical specifications
| Li-ion (Ah) | 6.0 5.0 4.0 3.0 2.0 1.5 |
|---|---|
| Capacity Machine screw | M4-M8(5/32"- 5/16) (") |
| Capacity Standard bolt | M5-M8(3/16"-5/16) (") |
| Capacity High strength bolt | M5-M6(3/16"-1/4) (") |
| Capacity Coarse thread (in length) | 22-125(7/8-4"-7/8) mm(") |
| Impacts Per Minute (IPM) Hard | 0-2700 |
| Impacts Per Minute (IPM) Medium | 0-2200 |
| Impacts Per Minute (IPM) Soft | 0-1400 |
| No Load Speed (RPM) Hard | 0-3200 |
| No Load Speed (RPM) Medium | 0-2000 |
| No Load Speed (RPM) Soft | 0-1200 |
| Max Fastening Torque | 40(355) N·m(in.lbs.) |
| Noise level | 77 db(A) |
| Dimensions (L x W x H) | 136x79x240(5-3/8x3-1/8x9-1/2) mm(") |
| Net weight | 1.2(2.7) kg(lbs) |
| BL Motor | ✓ |
| XPT | ✓ |
| Voltage | 18 V |
| Variable Speed | ✓ |
| Brake | ✓ |
| Reversing | ✓ |
| Built-in Job Light | ✓ |
| Carrying Case | ✓ |
