(EN / TH)

HS7010
Circular Saw



HS7010
Circular Saw

Circular Saw 185 mm (7-1/4") / 190 mm (7-1/2") 1,600 W

  

๐ High Power and Increased Motor-Burnout Resistance ๐ Up to 70% faster cutting than HS7000/HS7600 ๐ Powerful 1,600 W motor delivers 5,500 RPM for increased performance and job site durability ๐ Ergonomic rubberized front grip and handle provide added comfort ๐ Large cutting capacity (65 / 67 mm at 90°, 44 / 45 mm at 45°) ๐ Steel plate base ๐ Aluminum blade case for high durability and long tool life ๐ Aluminum diecast safety cover for high durability and long tool life ๐ Bevel cuts 0°- 45° for the most common cutting applications ๐ Well-balanced and lightweight for superior handling and performance ๐ Single action lever for quick adjustment of cutting depth ๐ Angular guide at rear for smooth and precise adjustment of bevel angle ๐ Flat motor housing design for stability when changing the blade

Standard Equipments: TCT saw blade, Rip fence, Hex wrench, Dust nozzle


Technical specifications

Continuous Rating Input 1,600 W
Wheel Diameter 185 - 190 mm
Hole diameter 20/ 30 mm
Max Cutting Capacity 65/ 67 mm
Max Cutting Capacity 45° 44/ 45 mm
No Load Speed 5,500 minˉ¹
Dimensions (L x W x H) 300 x 240 x 261 mm
Net weight 4 kg
Carbon Brush 303
Double Insulation
Dust Collection
