HS0600
Circular Saw



HS0600
Circular Saw

Circular Saw 260 mm (10-1/4") / 270 mm (10-5/8") 2,000 W

  

๐ Large cutting capacity (97 mm (3-13/16") at 90° with 260 mm (10-1/4") blade, 101 mm (4") at 90° with 270 mm (10-5/8") blade) and bevel capacity (0°-50°) ๐ Magnesium components create a lightweight saw that is well balanced and job site tough ๐ Compatible with optional guide rail for increased maneuverability ๐ Powerful 2,100 W motor delivers 4,300 RPM ๐ Rigid aluminum base provides smooth cutting thanks to its lightness, toughness and good bend resistance ๐ Rear angular guide for smooth and precise adjustment of bevel angle ๐ Dust nozzle is attachable for connecting to vacuum cleaner ๐ Make quick, one-handed adjustments using large, rubberized levers ๐ Flat motor housing design for stability when changing the blade ๐ Rear dust port exhausts sawdust away from operator for clean and comfortable operation ๐ Two-stage safety trigger switch minimizes accidental start up

Standard Equipments : TCT saw blade, Dust nozzle, Rip fence, Hex wrench, Wrench holder


Technical specifications

Continuous Rating Input 2,000 W
Wheel Diameter 255 - 270 mm
Hole diameter 25.4 mm
Max Cutting Capacity 97/101 mm
Max Cutting Capacity 45° 68/71 mm
No Load Speed 4,300 minˉ¹
Dimensions (L x W x H) 418 x 273 x 324 mm
Net weight 6.9 kg
Carbon Brush 153
Double Insulation
