DTW210
Cordless Impact Wrench

DTW210 Parts List (1.30 MB)

DTW210 Leaflet (15.39 MB)

DTW210
Cordless Impact Wrench

18V Cordless Impact Wrench 1/2" 250 N·m

  
Variable Speed
Brake
Reversing
Built-in-Job Light
Carrying Case

Features

  • Model DTW210 is an entry-level, compact-size cordless impact wrench powered by an 18V LXT Li-Ion battery, which is developed based on model DTW190.
  • By using a brushless motor, DTW210 achieves higher tightening performance and lighter and more compact body, compared with the current model. On top of that, it maintains the same strong price competitiveness as DTW190 through optimization of electrical components.
  • Compact and lightweight design at only 130 mm overall length
  • Brushless motor technology enhances fastening performance, while an integrated switch-controller assembly helps minimize cost increases.
  • Twin LEDs with preglow and afterglow functions
  • Optimal battery location
    Compared with the current DTW190, the battery has been repositioned closer to the grip centerline, helping reduce wrist strain during operation.
  • Variable speed control by trigger for precise fastening in a wide variety of applications
  • Electric brake for increased operator safety
  • Rubberized soft grip provides increased comfort on the job
  • Reversing switch is conveniently located
  • Belt clip (optional accessory) can be attached for increased operator comfort
  • Powered by Makita 18V LXT Li-Ion battery
  • Equipped with Battery protection circuit to protect against overloading, over-discharging and over-heating


Parts List
(1.30 MB)


Leaflet
(15.39 MB)

Available options

DTW201WV
Battary 18V LXT Basic 2Ah, Charger DCB18WA   


Technical specifications

No Load Speed 0 - 2,300 minˉ¹
Capacity Standard bolt M5 - M16 (3/16 - 5/8")
Capacity High strength bolt M5 - M14 (3/16 - 9/16")
Max fastening torque 250 N·m
Nut-busting torque 400 N·m
Impacts Per Minute 0 - 3,200 minˉ¹
Dimensions (L x W x H) 130 x 81 x 233 - 250 mm
Net weight 1.3 - 1.6 kg
