TW1000
Impact Wrench

TW1000
Impact Wrench

Impact Wrench 1" (25.4 mm) 1,000 N·m 1,200W

  

๐ Huge 1,000 N·m (738 ft.lbs.) of Power for Industrial Applications ๐ Large 25.4 mm (1") square drive capacity for heavy duty applications ๐ Efficient impact system (1,500 IPM) with less vibration ๐ Externally accessible brushes for easy replacement, and ball bearings for longer tool life ๐ Side handle rotates 360° for operator convenience ๐ Impact-resistant aluminum gear case with rubber boot protects the all metal gears and offers increased durability ๐ Rocker switch with forward/reverse operation for user convenience ๐ Ergonomically designed rubberized grip for increased comfort ๐ Conveniently located sky hook for continuous use or for convenient storage ๐ Friction ring anvil with retaining ring hole for secure socket retention ๐ Lightweight with plastic motor housing and handle ๐ Double insulation ๐ Great for High rise construction, HVAC, Installers, Bridge builders, Deck builders and many other high torque applications

Standard Equipments : Side grip


Technical specifications

Continuous Rating Input 1,200 W
Fastening capacities Standard bolt M24 - M30 (15/16 - 1-3/16")
Fastening capacities High strength bolt M22 - M24 (7/8 - 15/16")
Square drive 25.4 mm (1")
No Load Speed 1,400 minˉ¹
Impacts Per Minute (IPM) 1,500
Max fastening torque 1,000 N·m
Dimensions (L x W x H) 382 x 110 x 290 mm
Net weight 8.8 kg
Power Supple Cord 2.5 m
Carbon Brush 153
Double Insulation
Reversing
Carrying Case
