DCU601
Battery Powered Wheelbarrow
DCU601
Battery Powered Wheelbarrow
36V Wheel Battery Powered Wheelbarrow, Electric Lift
๐ Max load capacity up to 300 kg • on flat ground (0 - 3 degrees): 300 kg • on slope (3 - 12 degrees): 180 kg ๐ Electric lift • The switch on the battery box enables the user to lift up the flat frame to 1,020mm above ground level electrically (elevated to 1,020mm in approximately 30 seconds) • The electric lift is limited to use on a flat ground, therefore, the machine is equipped with a level gauge to check the leveling of the machine ๐ Compatible with various sizes of loads • L x W: 965 x 645 (mm) • The front, left, and right guards are designed to be easily lowered below the flat frame by lifting and sliding them, allowing for easy loading and unloading while dragging loads without lifting up them ๐ XPT (eXtreme Protection Technology) / IPX4-compatible ๐ High water-resistance allows to operate the machine even if it is wet with water ๐ Powered by two 18V LXT batteries in series • Two or four batteries can be installed for a 2-series/2-parallel connection for a secure amount of work • Equipped with a battery selection switch to choose which combination of 2 batteries to use ๐ Traveling speed change • Selection of 3 Forward speeds and F/R rotation by push button • Stepless variable speed control by switch trigger in each range ๐ Tubed tire (used for both front and rear wheels) • No deformation and less air leakage even in long-term storage • 2-piece split wheel is used for easy repair ๐ Driving wheels (Front wheels) touch the ground stably ๐ Rear wheel axle is designed to tilt to enable Front wheels (driving wheels) to stably touch the ground for reliable driving even on bumpy road surfaces ๐ Double tires (Rear wheels only) • Double tires, each of which rotates independently, improve swivel performance (especially in U-turn when the rear wheels swivel 180º) • Small diameter double tire structure allows for low platform and high load capacity ๐ Swivel lock fixes the direction of rear wheels ๐ Headlights • turn on/off by pressing a light button on the battery box • turn off automatically with no operation for 10 minutes ๐ Red LED taillight • indicates the presence of the wheelbarrow in the dark to oncoming drivers, walkers, etc • lights up together with headlights at the same time by pressing a light button • turns off automatically with no operation for 10 minutes ๐ Warning beeper • can alert people around you • Beep button is located on the inside of Switch box on Right handle ๐ Tool-less handle height adjustment ๐ Handle height can be adjusted according to user's height without tool simply by turning 2 knob screws ๐ Equipped with electric and electromagnetic brakes on top of hand lever-operated mechanical brake ๐ Neutral mode • shuts off the power transmission between the motor shaft and the axle in case of no battery installation, low battery capacity or broken motor, enabling to drive the wheelbarrow manually • Neutral lever is operable only when the hand brake lever is locked
Technical specifications
Continuous Use | w/ BL1860B x4 : 100 min. |
---|---|
Max load capacity | 300 kg |
Traveling speed | 5.0 / 3.5 / 1.5 km/h |
Potential travel distance | 7.2 km |
Max climbing angle | 12° |
Dimensions (L x W x H) | 1,400 x 730 x 820 mm |
Net weight | 145 kg |
