(EN / TH)

UR201C
Battery Powered Grass Trimmer

UR201C
Battery Powered Grass Trimmer

Grass Trimmer Battery Powered

  

๐ 36V high power drive system with BL motor provides 1 kW max output power similar to 30 mL class engine grass trimmers ๐ Excellent ability to perform continuous cutting achieved by high cooling capacity that suppresses heat generation of the controller and motor ๐ 43 cm cutting width with nylon cutting head for user convenience ๐ 36V high power drive system using model PDC01 portable power pack; Up to four batteries can be carried on user's back, enabling long continuous operation while providing more lightweight tool body ๐ Automatic torque Drive Technology (ADT) adjusts speed and torque during operation for optimum performance ๐ Active Feedback sensing Technology (AFT) turns the motor off if blade rotation is suddenly forced to stop ๐ IPX4 level water resistant ๐ WetGuard; Excellent water-resistant performance ๐ Rear end mounted motor makes the tool balance similar to engine grass trimmers ๐ Constant speed control minimizes reduction in rotation speed under load ๐ 3-speed options (Low / Medium / High) allows the operator to match speed to application ๐ Reverse switch for easy removal of grass clippings from the cutting tool ๐ Electric brake for maximum productivity and increased operator safety ๐ Battery protection circuit protects against overloading, over-discharging and over-heating ๐ Soft start feature for added motor protection ๐ On-tool hex wrench for fast and easy blade changes and keeping it from lost ๐ Low noise level suitable for use in residential areas and public spaces ๐ Zero emissions and reduced maintenance; no need for gas or oil. The best choices for use in resorts, public places and residential areas

Standard Equipments : Metal blade / Nylon cutting head / Plastic blade, Blade cover (for the product with metal blade), Accessory bag, Hex wrench, Box wrench, Shoulder belt


Technical specifications

Max out put 1.0 kW
Cutting width : Metal blade 255 mm
Cutting width : Nylon cutting head 430 mm
Cutting width : Plastic blade 305 mm
No load speed (Metal blade ) 0 - 7,000 / 5,500 / 4,600 minˉ¹
No load speed (Nylon cutting head ) 0 - 5,500 / 5,000 / 4,600 minˉ¹
Spindle size M10 x 1.25 LH
Continuous Use PDC01 : 26 - 58 min.
Sound Pressure Level 80.0 dB(A)
Sound Power Level 91.8 dB(A)
Dimensions (L x W x H) 1,795 x 400 x 269 mm
Net weight 4.7 kg
Variable Speed
Brake
Reversing
Electronic 3-Speed
Constant Speed
Soft Start
