AN902
Construction Coil Nailer

AN902
Construction Coil Nailer

Construction Coil Nailer 90 mm (3-1/2")

  

๐ More power and less weight for increased versatility ๐ 2-mode trigger allows operator to select sequential or contact nailing operations ๐ Toolless depth adjustment engineered for more precise flush and countersink nailing ๐ Easy access nose design for clearing jammed nails ๐ Easy loading canister with nail size adjustment provides maximum versatility ๐ Rubberized handle for better fit and added comfort ๐ Metal exhaust cover plate engineered for increased tool life ๐ Drives 45 mm (1-3/4") to 90 mm (3-1/2") coil framing nails ๐ Rubber bumpers protect tool housing ๐ Sharp, pronounced spurs grip wood for controlled nailing at any angle ๐ Magazine holds up to 300 nails for high production applications ๐ Ideal for framing, sheathing, fencing, decking, pallets, crating and more ๐ Includes no-mar tip to help minimize damage to work surface

Standard Equipments: Safety goggles, Nose adapter, Oil supply (country-specific), Hex wrench


Technical specifications

Capacity 45 - 90 mm (1-3/4 - 3-1/2")
Operating pressure 0.49 - 0.83 MPa (71 - 120 PSI)
Magazine capacity 150 - 300
Net weight 3.5 kg
Depth Adjustment
Sequential and Bump-fire
Wire Collated Nail
Inlet Filter
