TL064D
Cordless Angle Impact Driver

TL064D
Cordless Angle Impact Driver

12V max Cordless Angle Impact Driver 60 N·m

  

๐ Compact & lightweight right angle impact driver for fastening and loosening in tight spaces ๐ 60 N·m (530 in.lbs.) of maximum torque and 0-3,000 IPM ๐ Variable speed (0-2,000 RPM) for a range of applications from auto repair to cabinet installation ๐ Large conveniently located paddle switch for comfortable operation ๐ Over one foot of tool extension for extra reach into deep tight spaces ๐ LED light with preglow and afterglow feature illuminates the work area ๐ Soft grip handle provides increased comfort on the job ๐ Compact angled head for easy access in confined spaces (Center height: 18 mm (11/16"), Head height: 53 mm (2-1/8")) ๐ Machined aluminum head for added durability ๐ 360 degrees rotatable head enables operation from optimum angle ๐ Convenient 6.35 mm (1/4") hex chuck for quick bit change ๐ Conveniently located forward/reverse switch ๐ Phosphorescent bumper ring for locating tool in dark work areas ๐ Durable, reversible belt clip convenient for temporary tool hanging ๐ Battery protection circuit protects against overloading, over-discharging and over-heating ๐ Slide style battery and improved ergonomic grip ๐ Multi-contact terminals ensure stable contact with battery ๐ Part of the expanding 12V max CXT series, combining performance with superior ergonomics in a compact size ๐ Optional straight head and ratchet head are compatible with those for DTL060 / DTL061. ๐ Electric brake for maximum productivity

Standard Equipments : Phillips bit, Belt clip


Technical specifications

Capacity Machine screw M4 - M8
Capacity Standard bolt M4 - M12
Capacity High strength bolt M4 - M8
No Load Speed 0 - 2,000 minˉ¹
Impacts Per Minute (IPM) 0 - 3,000
Max fastening torque 60 N·m
Dimensions (L x W x H) 361 x 66 x 86 mm
Net weight 1.2 - 1.6 kg
Variable Speed
Brake
Reversing
Built-in-Job Light
Carrying Case
