SK209GD
Rechargeable Green Multi Line Laser

SK209GD
Rechargeable Green Multi Line Laser

12V max Rechargeable Green Multi Line Laser

  

๐ High Brightness Green Laser for Increased Visibility at Bright Site ๐ Horizontal line > 2-Vertical line > 2-Vertical line/horizontal line (Loopback switch system) ๐ High accuracy +/-1 mm @ 10 m ๐ Up to 40 hours of continuous illumination in high visibility mode with BL1041B ๐ Laser wavelength 515 nm / Lower dot beam wavelength 650 nm ๐ Indication method: Automatic vertical line indication by gimbal mechanism*¹ ๐ Control method: Magnet damper method control ๐ Brightness selection: 3 Modes (constant pulse) Eco mode > Normal mode > Bright mode (Loopback switch system) ๐ Mode memory function: When the power is turned ON, the laser beam mode will be the same mode as the last time turned OFF ๐ DC jack allows power to be supplied from LXT batteries by using USB adapter ADP05 and power supply cable ๐ eXtreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions (Dust and water resistance with IP54 rating for increased durability) ๐ ESD (Electrostatic discharge) protective measures: Level 4 (IEC61000-4-2) ๐ Compatible wit CXT batteries ๐ Shock absorbing construction minimizes the tool from vibration during transport

Standard Equipments : Laser viewing glass, Shoulder strap, Storage case


Technical specifications

Leveling accuracy +/- 1 mm / 10 m
Self-leveling range
Number of laser lines 3 (2V1H)
Laser type Laser class 2 : 515 nm
Operating time (approx.) 15 - 40 hours
Protection class IP%$
Dimensions (L x W x H) 122 x 110 x 225 mm
Net weight 1.5 - 1.6 kg
Carrying Case
