DCC500
Cordless Dustless Cutter



DCC500
Cordless Dustless Cutter

18V Cordless Cutter 125 mm (5") Dry Type

  
Brake
Soft Start
Bevel Cutting 45 left
Dust Collection
Built-in-Job Light

Features

  • BL motor provides high power and excellent cutting performance
  • 8,800 RPM provides cutting efficiency similar to DGA504
  • Built-in LED light for better illumination and more accurate work
  • Water-resistance compatible with XPT
  • Auto-start Wireless System (AWS) connects to compatible vacuum cleaners with Bluetooth
  • Automatic torque Drive Technology (ADT) adjusts cutting speed and torque during cut for optimum performance
  • 360° rotatable dust collecting port for vacuum cleaner / dust bag Connection
  • Compatible with optional guide rail for increased maneuverability
  • Dust cover to minimize dust scattering around
  • Dust proof switch covered with dust cover minimizes contamination of motor
  • Up to 125 mm (5") diameter diamond wheel can be used
  • Wide blade case enables use of curved diamond wheel
  • Cuts up to 40 mm (1-9/16") with 125 mm (5") wheel
  • Powerful cutting in stone, masonry, tile, concrete & more
  • Flat motor housing allows tool to stand upright when changing blades
  • Large top handle design for increased comfort
  • Lock-on button for continuous use operation (for tool with lock-on button)
  • Two-stage safety trigger switch minimizes accidental start up (for tool with lock-off button)
  • On-tool hex wrench for fast and easy blade changes and keeping it from lost.
    Battery protection circuit protects against overloading, over-discharging and over-heating

Standard equipment: Diamond wheel, Dust bag, Hex wrench


Technical specifications

Blade diameter 125 mm
Hole diameter 20 mm
Max Cutting Capacity 40 mm
Max Cutting Capacity 45° 27 mm
No Load Speed 8,800 minˉ¹
Dimensions (L x W x H) 231 x 158 x 172 mm
Net weight 2.5 - 3.0 kg
